Altivar Process ATV630 – Variable Frequency Drive – 22 kW – IP21 – 400–480 V
ATV630D22N4 is a variable frequency drive manufactured by Schneider Electric. It is part of the Altivar 630 range, which is a series of control cabinets and frequency drives designed for the management of electric motors.
Description
This model is used to control the speed of three-phase electric motors, particularly in industrial applications such as managing pumps, fans, compressors, and more.
It is designed to improve the energy efficiency of installations and reduce mechanical wear on motors.
Technical Specifications:
Power: The ATV630D22N4 is designed for a 22 kW motor (approximately 30 horsepower).
Supply Voltage: It is intended for three-phase power systems at 400 V, with a typical voltage range of 380–480 V.
Current: This model can handle a current of approximately 47.8 A.
Technology:
It incorporates advanced motor control features such as torque management, smooth acceleration and braking, as well as protection against overloads and short circuits.
The ATV630D22N4 also supports communication functions with industrial networks via protocols like Modbus, CANopen, Ethernet/IP, and more.
Control Features:
It can be controlled by analog signals (0–10 V or 4–20 mA) or through digital communication interfaces.
The model also includes a control panel with a display for easy configuration and monitoring.
Additional Features:
Energy Efficiency: Optimizes energy management to reduce electricity consumption.
Motor Protection: Provides built-in protections to prevent motor overheating and overload.
Compact and Modular Design: The ATV630D22N4 is designed for quick and easy installation with a reduced footprint.
Specific Applications:
- Suitable for demanding industrial environments where precise speed control and energy consumption management are required.
- Used in ventilation, air conditioning, oil and chemical industries, as well as in water treatment facilities, among others.
The ATV630D22N4 is a high-performance and reliable frequency drive, designed for 22 kW motors, offering advanced energy management and control and communication functions tailored to modern industrial needs.
Features
Semiconductor
