WEG electric motor – MGL630, 3000 kW, 6-pole, 690V, IC86W, 45 Hz, B3L
WEG motors are electric motors manufactured by WEG S.A., a Brazilian company globally recognized for its electrical and industrial solutions. Founded in 1961, WEG is one of the largest manufacturers of electric motors worldwide and offers a wide range of products suited for various industries.
With a cast iron frame, flexible mounting options, solid and sturdy feet, and reduced operating temperatures, the W22 motors are perfectly suited for a wide variety of industrial applications and comply with the efficiency level according to IEC 60034-30-1 standard.
Description
The WEG MGL630 3000 kW, 6-pole motor with B3L mounting, 690 V voltage, IC86W cooling system, and operation at 45 Hz is designed for very high-power industrial applications.
Key Features:
Power and Speed: This motor delivers an exceptional power output of 3000 kW with a rotational speed of 1000 rpm, suitable for applications requiring high torque and low speed.
Energy Efficiency: Rated IE2, it provides high energy efficiency, helping reduce energy consumption and operational costs.
Mounting and Design: The B3L mounting indicates a motor with foot and flange mounting, facilitating installation in various configurations. The MGL series is specially designed for very high-power applications, offering optimal performance and increased reliability.
Voltage and Frequency: Designed for 690 V at 45 Hz power supply, this motor is suitable for specific industrial installations requiring reduced operating frequency.
Protection and Insulation: With an IP55 protection rating, it is safeguarded against dust and water jets, ensuring enhanced durability. Insulation class F allows a maximum operating temperature of 155°C, providing a safety margin for demanding operating conditions.
Cooling: The IC86W cooling system ensures efficient heat dissipation, even in harsh operating environments.
Typical Applications:
- Industrial pumps
- High-capacity compressors
- Crushers and grinders
- Industrial turbines
- High-power ventilation systems
These features make the WEG MGL630 3000 kW motor a reliable and efficient choice for very high-power industrial applications requiring high performance and long-term reliability.
Features
Induction
