Easy UPS 3S 20 kVA 400V 3:3 UPS, 2 internal 7Ah
The Easy UPS 3S (model E3SUPS20KHB1) is a 20 kVA three-phase uninterruptible power supply designed to ensure continuous power in environments such as data centers and electrical rooms. It delivers an output power of 20 kW and operates with online double conversion technology, providing optimal protection against voltage fluctuations.
Description
This UPS features advanced product functionalities, competitive specifications, and a robust electrical design, ensuring business continuity in data centers or electrical rooms. It is a 20 kVA UPS with exceptionally easy installation, operation, maintenance, and servicing, making it ideal for small and medium-sized businesses. It includes a dust filter and coated panels compliant with harsh environments.
Main Features:
Power and Capacity: 20 kVA (20 kW)
Input and Output Voltage: 400 V three-phase
Battery Runtime: Approximately 15 minutes at full load (20 kW)
Batteries: VRLA (sealed lead-acid) technology with a voltage of 240 V
Dimensions: 380 mm (W) x 1,400 mm (H) x 928 mm (D)
Weight: 446 kg
Noise Level: 60 dB
Certifications: CE, EAC, RoHS, IEC 62040-1-1, IEC 62040-2, IEC 62040-3, IEC 62040-4, ISTA 2B, RCM, WEEE, REACH
Installation and maintenance of the Easy UPS 3S are simplified thanks to its modular design and user-friendly interface. It is also equipped with a dust filter and coated panels compliant with harsh environments, providing enhanced protection against severe ambient conditions.
Features
On-line Double conversion
VRLA Batteries Dust Filter Installation Guide
