Stabilisateurs de tension digitaux électromécaniques - ORION PLUS 400-20

Main Features:

• Input voltage regulation range: -20% to +20% of the nominal voltage.
• Rated power: 400 kVA.
• Output voltage accuracy: ±0.5%.
• Load capacity: Supports loads up to 100% of the rated power, with tolerance for load imbalances up to 100%.
• Cooling: Natural ventilation, assisted by fans when the internal temperature exceeds 35°C.
• Operating ambient temperature: -25°C to +45°C.
• Instrumentation: Equipped with digital multimeters on both input and output for precise monitoring of electrical parameters.
• Surge protection: Class II surge arrester on output.
• Dimensions: Specific dimensions may vary depending on the exact model configuration.

The ORION PLUS 400 kVA ±20% model is designed to regulate the voltage of each phase independently, ensuring balanced power supply even under asymmetric loads. It is also equipped with an optimal voltage return system via supercapacitors in the event of a power outage, guaranteeing continuity of service.
